UCC5870QDWJRQ1 Texas Instruments - Yeehing Electronics
Automotive, 3.75kVrms 30A single-channel functional safety isolated gate driver for IGBT/SiC
Pricing (USD)
Quantity | Unit Price |
1 — 99 | 9.794 |
100 — 249 | 8.555 |
250 — 999 | 6.596 |
1,000 + | 4.13 |
The above prices are for reference only.
Specifications
For more information, please refer to datasheet
Documents
UCC5870QDWJRQ1 Datasheet |
More Information
The UCC5870-Q1 device is an isolated, highly configurable single-channel gate driver targeted to drive high power SiC MOSFETs and IGBTs in EV/HEV applications. Power transistor protections, such as shunt-resistor–based overcurrent, NTC-based overtemperature, and DESAT detection, include selectable soft turn-off or two-level turn-off during these faults. To further reduce the application size, the UCC5870-Q1 integrates a 4-A active Miller clamp during switching, and an active gate pulldown while the driver is unpowered. An integrated 10-bit ADC enables monitoring of up to six analog inputs and the gate driver temperature for enhanced system management. Diagnostics and detection functions are integrated to simplify the design of ASIL-D compliant systems. The parameters and thresholds for these features are configurable using the SPI interface, which allows the device to be used with nearly any SiC MOSFET or IGBT.
