UCD74106RGMT


YeeHing #: Y012-UCD74106RGMT
Inventory: 6000

Feel free to reach out to us for more information.
Click the button below to unveil exclusive discounts and delightful surprises.

Description

UCD74106RGMT Texas Instruments - Yeehing Electronics

Digital Synchronous Buck Power Driver

Pricing (USD)

Quantity Unit Price
1 — 99 2.347
100 — 249 2.057
250 — 999 1.442
1,000 + 0.81

The above prices are for reference only.

Specifications

Manufacturer Texas Instruments
Product Category Gate Drivers
RoHS Y
Product MOSFET Gate Drivers
Type High Side, Low Side
Mounting Style SMD/SMT
Package / Case VQFN-13
Number of Drivers 1 Driver
Number of Outputs 1 Output
Output Current 6 A
Supply Voltage - Min 2.2 V
Supply Voltage - Max 18 V
Operating Supply Current 4 mA
Minimum Operating Temperature - 40 C
Maximum Operating Temperature + 125 C
Series UCD74106
Packaging Reel
Operating Temperature Range - 40 C to + 125 C
Output Voltage 3.3 V
Technology Si
Brand Texas Instruments
Operating Supply Voltage 2.2 V to 18 V
Product Type Gate Drivers
Factory Pack Quantity 250
Subcategory PMIC - Power Management ICs
Unit Weight 0.000861 oz

For more information, please refer to datasheet

Documents

UCD74106RGMT Datasheet

More Information

The UCD74106 is a complete power system ready to drive a buck power supply (). High-side MOSFETs, low-side MOSFETs, drivers, current sensing circuitry and necessary protection functions are all integrated into one monolithic solution to facilitate minimum size and maximum efficiency. Driver circuits provide high charge and discharge current for the high-side NMOS switch and the low-side NMOS synchronous rectifier in a synchronous buck circuit. The MOSFET gates are driven to 6.25 V by an internally regulated VGG supply. The internal VGG regulator can be disabled to permit the user to supply an independent gate drive voltage. This flexibility allows a wide power conversion input voltage range of 2.2 V to 18 V. Internal Under Voltage Lockout (UVLO) logic insures VGG is good before allowing chip operation.
