Texas Instruments
XIO2213BZAY
XIO2213BZAY
Regular price
$4.48 USD
Regular price
Sale price
$4.48 USD
Unit price
per
Couldn't load pickup availability
XIO2213BZAY Texas Instruments - Yeehing Electronics
x1 PCIe to 1394b OHCI host controller
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 10.629 |
| 100 — 249 | 9.284 |
| 250 — 999 | 7.159 |
| 1,000 + | 4.48 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | PCI Interface IC |
| RoHS | Y |
| Type | Bridge - PCIe to PCI |
| Operating Supply Voltage | 3.3 V, 1.95 V, 1.5 V |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 85 C |
| Mounting Style | SMD/SMT |
| Package / Case | nFBGA-167 |
| Packaging | Tray |
| Data Rate | 800 Mb/s |
| Series | XIO2213B |
| Brand | Texas Instruments |
| Development Kit | XIO2213BEVM |
| Moisture Sensitive | Yes |
| Product Type | PCI Interface IC |
| Factory Pack Quantity | 160 |
| Subcategory | Interface ICs |
| Unit Weight | 0.021870 oz |
For more information, please refer to datasheet
Documents
| XIO2213BZAY Datasheet |
More Information
The TI XIO2213B is a PCIe to PCI translation bridge, where the PCI bus interface is internally connected to a 1394b open host controller/link-layer controller with a 3-port 1394b PHY. The PCIe to PCI translation bridge is fully compatible with the PCI Express to PCI/PCI-X Bridge Specification, Revision 1.0. Also, the bridge supports the standard PCI-to-PCI bridge programming model. The 1394b OHCI controller function is fully compatible with IEEE Std 1394b and the latest 1394 Open Host Controller Interface (OHCI) Specification.
